Voltage Drop Calculator

Estimate circuit voltage drop using wire size, material, current, phase type, and run length. Compare drop percentage and get a quick wire size suggestion for your target.

Circuit Inputs
Set electrical and cable parameters for drop estimation.

Estimated Voltage Drop

8.991 V

3.75% of source voltage

Voltage at load

231.009 V

Drop percentage

3.75%

Power loss

269.7 W

Wire resistance

0.999 Ω/1000ft

Recommended AWG for Target Drop
Based on current, voltage, length, and selected conductor material.

Suggested minimum wire size to stay under 3%: 4/0 AWG (107 mm²).

Voltage Drop Formulas
Core equations used by this calculator.

Vdrop = 2 × I × R × L (DC / single-phase)

Vdrop = sqrt(3) × I × R × L (three-phase)

Drop% = (Vdrop / Vsource) × 100

Vload = Vsource - Vdrop

Here, R is conductor resistance in ohms per 1000 ft and L is one-way length in thousands of feet.

What Changes Voltage Drop?
Design factors that raise or reduce drop.
Length: Longer runs increase total resistance and drop.
Current: Higher load amps produce higher voltage drop.
Wire size: Larger conductors have lower ohms and lower drop.
Material: Copper generally drops less voltage than aluminum at the same size.
How to Use This Voltage Drop Calculator
Fast 4-step method for branch circuits and feeders.
1

Enter source voltage and load current.

2

Select phase type (DC, single-phase AC, or three-phase AC).

3

Choose conductor material and AWG size.

4

Input one-way run length and check drop percentage against your design target.

Common AWG Reference (Quick Table)
Typical copper resistance values used for fast estimation.
AWGArea (mm²)Copper (Ω/1000ft)Aluminum (Ω/1000ft)
4/01070.0490.079
3/0850.0620.1
2/0670.0780.126
1/053.50.0980.158
142.40.1240.199
233.60.1560.252
326.70.1970.317
421.20.2490.401
613.30.3950.637
88.370.6281.014
105.260.9991.612
123.311.5882.563
142.082.5254.078
